Crown block sheave
Ⅰ. Product Description
The frame of the crown block is made with high strength steel material. Working pulley block are set slantingly to counteract the torsion of sheave and make side board of traveling block face to derrick.
The pulley groove is undertaken middle-frequency quencher so as to extend operating life of sheaves. Working sheave are assembled with double-conic bearing, wherein each bearing has its individual lubricating channel.
Rope bar are provided to prevent the wire rope from crossing or failing out the groove. The Crown block is also equipped with wooden buffer and protection net to prevent bump. It is equipped with derrick crane as well for repairing the crown block.
Sand sheaves and auxiliary sheaves Assy can be provide as the requirement. climbing assistor and falling-proof device can be installed according to various requirements
. Besides, sheaves and bearing are interchangeable with its matched crown block.
. Note: Customized design and configuration is available to meet different requirements
|
Max diameter |
≤2000mm |
brand |
Munger |
|
size |
TC315 |
use |
well drilling |
|
(mm)overall size |
Φ1270XΦ360X130 |
(kg)weight |
350 |
Ⅱ. Packaging & Shipping
Package: Wooden box, iron box or according to your request
Delivery: In 15 workdays after order confirmed, air and sea transport are both acceptable
Ⅲ. Our Services
1. Our company is located in the west of China with professional experience ,our products strictly implement the ISO 9001:2000 Management System and API 7k&ASY 5138 Standard .
2. We are professional mud pump parts manufacturer over 100,000,000 anual sales in total, we will help you to cut down the cost. We can customize all kinds of mud pump parts according to your request.
3. We promise to respond your inquiry in 8 hours, ensure the quality and better after-sale service.
